SMBJ28A

600W, surface mount, transient voltage suppressor, 28V, RoHS Compliant

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.04~0.05 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.04~0.05

PartNumber:: SMBJ28A

Brand:: Vishay Siliconix - Vishay | Pack: DO | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Keyanyun's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-06

From Other Seller

Part Number:SMBJ28A
US $0.04 - 0.05
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SMBJ28A is a 600W surface mount transient voltage suppressor.

Parametrics

SMBJ28A absolute maximum ratings: (1)Peak Pulse Power Dissipation (Non repetitive current pulse derated above TA = 25℃), PPK: 600 W; (2)Peak Power Derating Above 25℃, Pder: 4.8 W/℃; (3)Peak Forward Surge Current, 8.3ms Single Half Sine Wave Superimposed on Rated Load, IFSM: 100 A; (4)Steady State Power Dissipation @ TL = 75℃, PM(AV): 5.0 W; (5)Instantaneous Forward Voltage @ IPP = 35A, VF: 3.5V at VBR<100V; 5.0V at VBR≧100V VF; (6)Operating Temperature Range, Tj: -55 to +150℃; (7)Storage Temperature Range, TSTG: -55 to +175℃.

Features

SMBJ28A features: (1)600W Peak Pulse Power Dissipation; (2)5.0V - 170V Standoff Voltages; (3)Glass Passivated Die Construction; (4)Uni- and Bi-Directional Versions Available; (5)Excellent Clamping Capability; (6)Fast Response Time; (7)Lead Free Finish/RoHS Compliant.
