Product Summary

The 1SMB5919BT3G is a 3 Watt plastic surface mount zener voltage regulator.

Parametrics

1SMB5919BT3G absolute maximum ratings: (1)Maximum Steady State Power Dissipation, PD: 3.0W at TL = 75℃; Measured at Zero Lead Length: 40mW/℃; Derate Above 75℃: 40mW/℃; (2)Thermal Resistance from Junction-to-Lead, RθJL: 25℃/W; (3)Maximum Steady State Power Dissipation @ TA = 25℃, PD: 550mW; Derate Above 25℃: 4.4mW/℃; (4)Thermal Resistance from Junction-to-Ambient, RθJA: 226℃/W; (5)Operating and Storage Temperature Range, TJ, Tstg: -65 to +150℃.

Features

1SMB5919BT3G features: (1)Zener Voltage Range - 3.3 V to 200 V; (2)ESD Rating of Class 3 (>16 kV) per Human Body Model; (3)Flat Handling Surface for Accurate Placement; (4)Package Design for Top Side or Bottom Circuit Board Mounting; (5)Pb-Free Packages are Available.

Diagrams

1SMB5919BT3G circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
1SMB5919BT3G
1SMB5919BT3G
ON Semiconductor
Zener Diodes 5.6V 3W
Data Sheet
0-1: $0.20
1-25: $0.17
25-100: $0.11
100-500: $0.09
