ES2D

surface mount, fast efficient plastic rectifier, 200V, 2A, DO-214AA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.03~0.03 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.03~0.03

PartNumber:: ES2D

Brand:: Vishay Siliconix - Vishay | Pack: DO | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Keyanyun's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-03

From Other Seller

Part Number:ES2D
US $0.03 - 0.03
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ES2D is a surface mount fast efficient plastic rectifier.

Parametrics

ES2D absolute maximum ratings: (1)Device marking code:ED; (2)Maximum repetitive peak reverse voltage:200V; (3)Maximum RMS voltage:140V; (4)Maximum DC blocking voltage:200V; (5)Maximum average forward rectified current at TL=110℃:2.0A; (6)Peak forward surge current:50.0A; (7)Typical junction capacitance:18.0pF; (8)Maximum thermal resistance:75.0℃/W; (9)Operating junction and storage temperature range:-55 to +150℃.

Features

ES2D features: (1)Plastic package has Underwriters Laboratory Flammability Classification 94V-0; (2)For surface mount applications; (3)Low profile package; (4)Built-in strain relief; (5)Ideal for automated placement; (6)Easy pick and place; (7)Glass passivated chip junction; (8)Superfast recovery times for high efficiency; (9)Low power loss, high efficiency; (10)High temperature soldering: 250℃/10 seconds at terminals.
