Product Summary
The ES2J is a 2.0 A Super Fast Surface Mount Rectifier.
Parametrics
ES2J absolute maximum ratings: (1)Maximum Recurrent Peak Reverse Voltage: 600V; (2)Maximum RMS Voltage: 420V; (3)Maximum DC Blocking Voltage: 600V; (4)Maximum Average Forward Rectified Current:2.0A; (5)Peak Forward Surge Current, 8.3 ms Single Half Sine-wave Superimposed on Rated Load (JEDEC method): 50A; (6)Maximum Instantaneous Forward Voltage @ 2.0A: 1.7V; (7)Operating Temperature Range:-55 to +150℃; (8)Storage Temperature Range:-55 to +150℃.
Features
ES2J features: (1)Glass passivated junction chip ; (2)For surface mounted application ; (3)Low profile package ; (4)Built-in strain relief ; (5)Ideal for automated placement ; (6)Easy pick and place ; (7)Superfast recovery time for high efficiency ; (8)Glass passivated chip junction ; (9)High temperature soldering: 260℃/10 seconds at terminals ; (10)Plastic material used carries Underwriters Laboratory Classification 94V-O.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ES2J |
Taiwan Semiconductor |
Rectifiers 2A 600V |
Data Sheet |
|
|
||||||||||||
|
ES2JA |
Taiwan Semiconductor |
Rectifiers 2A,600V,SUPER FAST Surf Mt SMA Rect |
Data Sheet |
|
|
||||||||||||
