Product Summary
The SMB30A is a surface mount unidirectional and bidirectional transient voltage suppressor.
Parametrics
SMB30A absolute maximum ratings: (1)PEAK POWER DISSIPATION: Minimum 600W; (2)IFSM Peak Forward Surge Current 8.3ms single half sine-wave super imposed on rated load: 100 AMPS; (3)Steady State Power Dissipation, PM(AV): 5.0 WATTS; (4)Maximum Instantaneous forward voltage: SEE NOTE 4 ; (5)Operating Temperature Range: -55 to +150℃; (6)Storage Temperature Range: -55 to +175℃.
Features
SMB30A features: (1)Rating to 200V VBR; (2)For surface mounted applications; (3)Reliable low cost construction utilizing molded plastic technique; (4)Plastic material has UL flammability classification 94V-O; (5)Typical IR less than 1uA above 10V; (6)Fast response time: typically less than 1.0ps for Uni-direction,less than 5.0ns for Bi-direction,form 0; (7)Volts to BV min.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 SMB30A300 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
SMB30A300-E3/52 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 30V TVS/300V Diode |
Data Sheet |
Negotiable |
|
||||
|
SMB30A300-E3/5B |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 30V TVS/300V Diode |
Data Sheet |
Negotiable |
|
||||
|
SMB30A300HE3/52 |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 30V TVS/300V Diode Asymmetric |
Data Sheet |
Negotiable |
|
||||
|
SMB30A300HE3/5B |
Vishay Semiconductors |
TVS Diodes - Transient Voltage Suppressors 30V TVS/300V Diode Asymmetric |
Data Sheet |
Negotiable |
|
||||
